Description of signals in Laptop Fans

Question

My laptop has this fan, which I want to replace. But before blindly replacing it and make it work I am curious to know what all signals are associated the four wires: Black, Pink, Yellow & Red. I could not find a technical specification for this model (Asus BSB04505HA Fan).

enter image description here

score 3 · Accepted Answer · answered Aug 22 '13 at 12:58

3

PC fans have standardised pinouts, so this shouldn't be a concern for replacement. If you are curious, there are sites which show which cable is which.

answered Aug 22 '13 at 12:58

Martin

8,420
1
23
30

On the sticker on the fan DC05V is mention, Does that mean 5v input supply? – gpuguy Aug 22 '13 at 13:27
It says "5v" on the sticker on the fan doesn't it? – John U Aug 22 '13 at 13:51
The picture above shows 5V, but in real fan which I am having DC05V is mentioned – gpuguy Aug 22 '13 at 14:18
1

@gpuguy The leading zero is just that: a leading zero. It is still 5V DC. – JYelton Aug 22 '13 at 16:22
