3

I am having 3 Server: A, B, C. Details are:

  1. Server A: NGINX Server, URL: https://test1.example.com
  2. Server B: NGINX Server hosting NodeJS Web Application, URL: http://test2.example.com
  3. Server C: Apache2 Server hosting Django Web Application, URL: http://test3.example.com

Server A(NGINX Server) is front facing public facing server acting as load balancer using proxy_pass. Server B(NGINX Server) is having a form and submitting it through POST request to Server C(UWSGI Django Server using Apache2). The request is from Server B with url: https://test1.example.com/register to Server C but Server A is converting it to GET request.

So I am getting 2 request log one with POST and other with GET with same path "/register"

The setup is depicted in figure (Diagram is at the end of the post).

The configuration is as follows:

  1. Server A:

    server {


    listen 443 ssl http2; listen [::]:443 ssl http2; server_name test1.example.com;

    ssl_certificate /etc/ssl/test1/test1.example.com.crt;
    ssl_certificate_key /etc/ssl/test1/test1.example.com.key;



    Proxy/Loadbalancer configuration`

    Testing the request`

        location / {
          proxy_pass http://test2.example.com;
        }

        location /register/{
                proxy_pass http://test3.example.com;
        }


    }

  2. Server B:

    server {

    listen 80 default_server;

    listen [::]:80 default_server;

    root /var/www/html;

    # Add index.php to the list if you are using PHP
    index index.html index.htm;

    server_name test2.example.com;

    location / {
            #try_files $uri $uri/ =404;
             try_files $uri $uri/ /index.html;
    }

    access_log /var/log/nginx/access.log;
    error_log  /var/log/nginx/error.log;


    }

  3. Server C:

    <VirtualHost *:80>
    ServerName  test3.example.com
    ServerAdmin admin@example.com
    DocumentRoot /var/www/test


    Alias /static/ /var/www/test/webapp/static/ Alias /media/ /var/www/test/media/

    WSGIScriptAlias / /var/www/test/webapp/wsgi.py WSGIDaemonProcess cdac.in python-path=/var/www/test
    python-home=/var/www/test/venv processes=5 threads=8 WSGIProcessGroup cdac.in <Directory /var/www/test/webapp/> Options -Indexes Order deny,allow Allow from all Require all granted </Directory>

    LogLevel info

    PROJECT_NAME is used to separate the log files of this application

    ErrorLog /var/log/apache2/error.log CustomLog /var/log/apache2/access.log combined

Where am I going wrong.

Setup Diagram

0 Answers0
